Dwyer ACT-MI08-24VAC Pneumatic/Electric Actuator

Dwyer ACT-MI08-24VAC is a pneumatic and electric actuator designed for hazardous locations. It has a temperature range of -40 to 140°F and is available in 110VAC, 220VAC, 24VAC, or 24VDC power requirements. It has a NEMA 7 enclosure, 1/2" female NPT electrical connections, and a powder-coated aluminum construction. The DA series is double-acting, while the SR series is spring return. Standard features include a position indicator and two limit switches. The cycle time, power consumption, and duty rating can be found in the instruction manual. Accessory mounting is NAMUR standard and the modulating input is 4 to 20 mA. Specifications (Instrument-Sensor) Supply Voltage 24 VDC (Instrument-Sensor) NEMA Protection NEMA 7 (Instrument-Sensor) Supply Voltage 24 VAC (Instrument-Sensor) Supply Voltage 110 VAC Component Actuator (Instrument-Sensor) Hazardous Location Class Class I – Group C & D; Class II – Group E-G; Division I & II (Instrument-Sensor) Temperature Range -40 – 140°F/-40 – 60°C Sub Component Pneumatic/Electric Actuator (Instrument-Sensor) Supply Voltage 220 VAC Manufacturer Dwyer Instruments Features ISO 5211 Mounting configuration for easy installation Pneumatic actuators offer corrosion resistance anodized finish NAMUR mounting configuration on pneumatic actuators Two-position electric actuators include auxiliary limit switches Modulating electric actuators offer an output for position monitoring Be the first to review “Dwyer ACT-MI08-24VAC Pneumatic/Electric Actuator” Cancel replyYour email address will not be published. Required fields are marked *Your rating of this product Rate… Perfect Good Average Not that bad Very poor Name * Email * Save my name, email, and website in this browser for the next time I comment. Reviews There are no reviews yet.
